The Split Field Magnet (left) and the spectrometer (right) which was used in R413. The round blobs are cerenkov counters, in between
are scintillators, wire chambers and a bending magnet to measure the particle momentum.
|
The Split Field Magnet
|
The Split Field Magnet and the ISR tunnel.
|
